To meet market demand, Changzhou New Router NC Machinery Co.,Ltd, located in Jiangsu province, China, launched new NRT2515-2Z-8/NRT1315-4 engraving machine, which is designed particularly for tea tray flat/side making.
Mechanical Performance Parameters:
|
Performance index item
|
Standard value
|
|
NRT2515-2Z-8
|
NRT1315-4
|
|
Motion positioning accuracy
|
±0.02/300mm
|
|
Repeat positioning accuracy
|
0.02
|
|
X/Y/Z shaft working stroke
|
2500mm×1500mm×100mm
|
1300mm×1500mm×100mm
|
|
Plane carving table size
|
2500mm×1600mm Aluminum
|
1300mm×1600mm Aluminum
|
|
The side carving feed tooling
|
8 station special adjustable, skip2 sets
|
4 station special adjustable, skip1 sets
|
|
The Z axis space height
|
180mm
|
|
Spindle motor power / tool
|
￠80/1.5kw/￠10
|
|
Spindle motor cooling / spindle speed
|
Water cooled /7000 ～24000rpm
|
|
Idle fast movement speed
|
10m/min
|
|
Drive system
|
Stepping system
|
|
Working voltage
|
220v/50Hz
|
|
Machine tool structure
|
The bed and the frame are thick, beams, columns, a rail base, Z spindle carriage assembly such as iron, carved on the side of material tooling and machine tool can be separated.
|
Main Configuration:
|
|
|
|
NRT2515-2Z-8
|
NRT1315-4
|
|
|
Part of the
|
The name
|
Type specification
|
|
Mechanical machine
|
The X/Y/Z axis guide rail
|
Rectangular linear rolling guide
|
|
The X/Y axis drive
|
Rack and gear synchronous round belt reducer /Y axis double drive
|
|
The Z axis drive
|
Imported ball screw / double Z axis
|
Imported ball screw / single Z axis
|
|
Electricity and gas
|
Spindle motor
|
￠80/1.5kw/8Only
|
￠80/1.5kw/4Only
|
|
Frequency converter
|
220v/3.7kw/4 Only
|
220v/3.7kw/2 Only
|
|
Drive system
|
Step, the Y axis to increase
|
Step
|
|
Control system
|
MULTECH：P21-3 Version control system
|
MULTECH：P1-3 Version control system
|
