Applicable Industries: Garments sampling, large width tailoring, leather industry, shoemaking
decoration, furniture, advertisement, packing and printing, molding and art craft industries, etc.
Applicable Materials: Fabrics, leather, paper. bamboo ware, acrylic, glass, films and canvas,
wood, porcelain, acryl, cloth, etc.
Technical Parameters:
|
Model
|
JQ1630 fabric laser cutting machine
|
|
Laser Power
|
80W
|
|
Laser Type
|
CO2 sealed, glass laser tube, water cooling
|
|
Work Area
|
1600 X 3000 mm
|
|
Cooling Type
|
Water-cooled and Protection System
|
|
Engraving Scanning Speed
|
0-60000 mm/min
|
|
Cutting Speed
|
0-10000mm/min
|
|
Laser Output Control
|
1-100% Software Setting
|
|
Smallest Character Engraving
|
English: 1.0X1.0 mm
|
|
Highest Scanning Precision
|
2500DPI
|
|
Power Supply
|
AC 110-220V±10%, 50-60Hz
|
|
Operating Temperature
|
0°-45°C
|
|
Operating Humidity
|
5%-95%
|
|
Locating Precision
|
≤±0.01mm
|
|
Supported File Format
|
DSTPLTBMPDXFAI
|
|
Compatible Software
|
CORELDRAW PHOTOSHOP AUTOCADAll
Type of AUTOCAD Software in cloth
|
|
Slope Engraving
|
360°Slope Can Be Designed Easily
|
|
Driving System
|
3 phases stepper motor
|
|
Package Dimension
|
5500X2300X1600 mm
|
|
Net Weight
|
1300KGS
|
|
Gross Weight
|
1550KGS
|
|
Optional Spare Parts
|
Red dot pointer
|
|
Removable Spare Parts
|
Laser Tube and Lens
|
