Character Features
◆Characteristic design, adjusting cutting force and plotting speed at any time
◆European popular large screen high bright display, clearly to operate
◆USB interface optional, supporting plug in and off when power is on
◆Domestic popular plotting language, supporting many popular kinds of software at home and abroad
◆Unique double cutter position, double pressing strips for processing different kinds of materials
◆Compatible with many computer operation systems such as Windows XP,Vista,Windows7 (32bit&64bit)
Technical parameter(Practical Type)
|
Model Item
|
JK361
|
JK721
|
JK871
|
JK1101
|
JK1351
|
|
Max. Paper Width
|
360mm
|
720mm
|
870mm
|
1100mm
|
1350mm
|
|
Max. Plotting Width
|
270mm
|
630mm
|
780mm
|
1000mm
|
1260mm
|
|
Net Weight/Gross Weight
|
8/12kgs
|
11/20kgs
|
12/22kgs
|
14/26kgs
|
17/31kgs
|
|
Packing Size
|
60*34*39cm
|
95*34*43cm
|
110*34*43cm
|
133*34*43cm
|
158*34*43cm
|
|
Interface
|
COM, USB & LPT (optional)
|
|
Language Format
|
DMPL/HPGL
|
|
Max. Plotting Speed
|
500mm/s
|
|
Max.Cutting Force
|
500g
|
|
Cutting Tool
|
Imported hardness alloy steel blade
|
|
Power Supply
|
AC90V~AC240V
|
|
Operation Environment
|
Temperature:5℃~35℃
Relative humidity:(30%-50%)without condensation
|
|
Colors
|
White color, grey color, black color
|
