Printing pattern

Epson DX5 Print Head Micro-voltage Inkjet printing

Printing width

     1800 mm   (70inch)

Acceptable media width

     1800 mm

Media conditions

Media type

Ink cartridge

Maximum media thickness

Rolls or sheet of a width not less than A4 size or 210mm

Rollmedia weight

1.5mm

Type

                     25kg

For ink system

volumn

sublimation ink

color

220c/440cc ± 5cc

Great for independent continuous ink system

Double 4 colors C M Y K (8 Individual Ink Supply Systems)

Color Gamut

                                1.67 million colors

Print resolution

1440×1440dpi,720×1440dpi,720×1080dpi,720×720dpi,720×540dpi,540×1080dpi,540×720dpi

Media manipulation

Automatic paper feed, automatic cutter

Media sensor

Both sides, the front edge and the rear edge

Height of print head

Adjustable at both ends 1.2mm / 2.8mm

Print head cleaning

Automatic cleaning system and manual cleaning system

Instruction set

                         RD-RTL , RD-PJL

Connector

                         USB 2.0/ HIUSB

Power

Print mode

Energy-saving features

Standbymode

Max  1.7A/100V~240V±10%,50/60 Hz

                            Auto sleep

Max  0.5A/100V~240V±10%,50/60 Hz

Noise Level

Print mode  65db(A) or lower (Accord with ISO7779)

Standby Mode 40 db(A) or lower (Accord with ISO7779)

Packing size(with foothold) Width×height×depth

2680mm× 870mm× 940mm

Weight (with foothold)

198kg

Power consumption

                                Below 1500VA

Circumstance

Power on

Attachment

Power off

Temperture 20~32°C

Humidity 35~80%(No condensation)

Power line, Waste ink bottle, User Guide

Temperture 5~40°C

Humidity 20~80%(No condensation)
