Product Details:
Model:
Select Payment and Shipping Terms:
Min. Order Quantity:
1 Unit/Units
Place of Origin:
Min. Order:
125
FOB Price:
0.00-0.00 /
Shippment Port:
Payment Terms:
Show Buyers your Ability to Supply:
Production Capacity:
0
Delivery Time:
Packaging:
Mr. Andy Wang



Send a Message to this Supplier

Product Details Company Profile

Functions and Features



Carriage data adopts fiber to realize bi-directional communication and has no

        signal intervention.

Protecting printhead voltage from extra pressure.

Supporting multi copy print and area print and for convenlence of small image bulk

        print and large image sample print.

Supporting mirror print,and it is used for both sides jetting.

With the function of auiomatically provlding ink,and displaying ink state,and long

        time low liquid warring.

Special 4 bed heaters and sub tank heater onsure very good quality in the cold

       operation enxionment.



Technical Specifications





Model

CT3300K42

Printhead

KONICA512-42pl

No.of printhead

4/8

Color

Y,M,C,K

   Printing Speed

High speed

41m2/hr(4H)

81m2/hr(8H)

Standard

32m2/hr(4H)

64m2/hr(8H)

High Quality

13m2/hr(4H)

28m2/hr(8H)

Max media width

3.4m 134inch

Max printing width

3.2m 126inch

Printhead height

2-5mm above media adjustable

Media Types

Vinyl,Window Film,Flex,ets

RIP Software

ULTRAPRINT

Print interface

USB 2.0

Machine Dimension

4.52 x 0.87 x 1.42m

Package Dimension

4.76 x 1.05 x 1.59m

Net weight

650kg

Gross weight

750kg
