Product Details
Company Profile
|
Name：
|
YL-UV3822B
|
YL-UV3218B
|
YL-UV2814B
|
|
Class：
|
YL-SKUVB series
|
|
Print technology：
|
Drop-on-demand Piezo electric
|
|
Printhead：
|
4/5/7/10/12/14(spt255)
|
|
Print width：
|
3.50*2.05M
|
2.80*1.6M
|
2.50*1.3M
|
|
Print high：
|
10cm
|
|
Resolution：
|
1440dpi max
|
|
Speed：
|
2pass 24m/h ; 4pass 16m/h ; 6pass 8m/h
|
|
Locating mode：
|
Raster /servo
|
|
Color：
|
CMYK W LC LM
|
|
Media width：
|
3.80M*2.15M
|
3.20M*1.83M
|
2.83M*1.32M
|
|
Media handl：
|
Sheet to sheet
|
|
Media types：
|
KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc
|
|
Drying system ：
|
Uv lamp
|
|
File format：
|
TIFF,Postscript 3,JPEG,EPS,PDF
|
|
Working process：
|
Printmon software for windows xp
|
|
Rip：
|
Photoprint /maintop
|
|
Power supply：
|
50hz/60hz 220v(10%)20A
|
|
Operation environmeng：
|
(Tempperature )18-26(Humidity )40%-70%
|
|
Dimesion：
|
4.6m*2.2m*1.4m
|
4.2m*1.9m*1.4m
|
3.0m*1.4m*1.2m
|
|
Weight：
|
1800Kg
|
1500Kg
|
1200Kg
|
Guangzhou YiLong Technology Limited Company (Guangzhou Victory electronic) was founded in 1992, for many years continuously has devoted to the advertisement manufacture equipment, becomes industry in supplier by reason of the abundant technical force and the good sales network. After many year professional services as well as the multitudinous new old customer support, makes the company to grow strong unceasingly. Company's service also expands from the sole advertisement profession to the dress designing plotting equipment, the shoe pattern engraves draws, laser carving, CAD output unit contour new domain. This company by its original outstanding product quality.
The formidable marketing superiority as well as the consummation post-sale service, persisted the "quality first, the user sends " the management policy, unceasingly innovates day by day in the keen competition., Development. China joins WTO, provides the broad opportunity for the society, We anticipated hand in hand advances together with the more partner. Communal development.
