led UV cool light resorce Spectra polaris 15pl/35pl printhead LU3200 printer
Facebook Twitter Delicious Google Email this page
Product Details:
Model:
R2R
Select Payment and Shipping Terms:
Min. Order Quantity:
1 Sheet/Sheets
Place of Origin:
Min. Order:
189
FOB Price:
USD 32000.00-0.00 /Set
Shippment Port:
chinese city
Payment Terms:
T/T
Show Buyers your Ability to Supply:
Production Capacity:
1 Set/Sets
Delivery Time:
Packaging:
WOOD CASE
Miss. Zhao Danny



Send a Message to this Supplier

Product Details Company Profile

Machine name

Uranus LED UV R2R  LU3200  printer

class

URS LED UV series

Print technology

Drop-on-demand Piezo

Print head

 Spectra polaris 35pl/15pl(optional)

Speed

4pass 12m2/h ;  6pass 8m2/h ;  8pass 6m2/h ;10pass 4m2/h

Resolution

720*1000dpi(max)

Media types

KT board;PVC board;Plexiglass board;glass board;ceramic board,tile;metal board;leather and all the roll to roll material like flex banner,mesh,one way vision,vinyl etc

Media width

3.2m(126inch)

Color

C M Y K (LED UV ink)

Drying system

Double LED UV lamps

File format

TIFF,Postscript 3,JPEG,EPS,PDF

Working process

Photo print 6.0

Power supply

 100--240v 50hz/60hz

Dimension

4.52*2.10*1.5m

Data transmission



USB 2.0

Ink supply

Low ink director ,Negative Pressure ink supply

Printhead cleaning system

Positive pressure cleaning system

 Pre-heating

 no pre-heating

Operation environment

(Temperature )18-26 (Humidity )40%-70%

Print media

Roll media

Auto media feeding system&Take up system

Equipped

The warrantee period is one of year since the day of installation .free maintaince is offered for main board and motors within the warrantee period .This limited warrantee doesn't apply to consumable parts.
