Unit Module
|
|
Item
|
Ph16 full color
|
|
Pixel pitch
|
16mm
|
|
Size of Module
|
256×128mm
|
|
Density of Pixel
|
3906 Dots/
|
|
Constitution of Pixel
|
2R 1G 1B
|
|
LED Encapsulation
|
546
|
|
Resolution of Display
|
16×8
|
|
Power Consumption of Module
|
35W
|
|
Major technical parameters
|
|
The Optimum Viewing Distance
|
14m
|
|
The Optimum Vewing Angle
|
110°
|
|
Average Power Consumption
|
1200W/
|
|
Resolution of Cabinet
|
64×48
|
|
Size of Cabinet
|
1024×768mm
|
|
Weight of Cabinet
|
60kg
|
|
Driving Method
|
Static constant current
|
|
Frame Frequency
|
≥60hz/s
|
|
Refresh Rate
|
≥400hz/s
|
|
Lunminance of White Balance(CD/)
|
≥6500 CD/M2
|
|
Operating Environment Temperature
|
-20~45-30~ +55optional
|
|
Operating Voltage
|
220±10% or 110±10%
|
|
Grey Scale/Color
|
Displaying Colors≥16.7M(Synchronized)
|
|
Brightness Adjustment
|
256 levels of each color(R,G,B)can be adjusted manually,and 8 levels of each color can be adjusted automatically
|
|
Input Signal
|
RFS-videoRGBRGBHVYUVYC and COMPOSITION,ect.
|
|
Control System
|
PCTV non-linear editting card+DVI display card+main controller card+optic fibre transmission(optional)
|
|
Average No Failure Time
|
>10000 hours
|
|
Life-span
|
>100000 hours
|
|
Malfunction Dot Rate
|
0.0001
|
Company has a strong technical support. We have a R&D team with more than 20 members, who are over 10 years of researching experience in this field, possess world class laboratory, which makes present products more functional and post-products accessible. By continuous creation, Hiboled has applied a lot of patents and usually design new products and make samples within 40 days according to client’s requirement.
