Specification:
1. 1200X900mm engraving and cutting area
2. CO2 sealed laser tube
3. power: 60W, 80W, 100W, 120W
4. water cooled and no water alarm
5. automatic exhaust system
6. optional auxiliary rotary device can process cylinder objects
7. CE&FDA
Technical parameters:
|
Model
|
YH-G1290
|
|
Laser power
|
60W/80W/100W/120W
|
|
Platform size
|
1200X900mm
|
|
cutting area
|
1200X900mm
|
|
cutting speed
|
≤18000mm/min
|
|
engraving speed
|
≤36000mm/min
|
|
positioning precision
|
±0.01mm
|
|
appearance size
|
1740×1490×940mm
|
|
characters
|
2.0mm English letter
|
|
cooling system
|
water pump or water chiller
|
|
laser type
|
sealed co2 glass laser tube
|
|
whole power
|
≤1250W
|
|
format support
|
AI,PLT,BMP,DXF,DST
|
|
power supply
|
AC 220V±5%/50HZ-60HZ
|
|
gross weight
|
450KGS
|
Product features:
This is our newest product, we product this type laser machine to save money and materials for you.
· Professional design ideal, customized for the users in different industries, elegant appearance and practical.
· Professional moving control design, adopt imported motor of high power and high-quality transmission system, high speed and high precision.
· Complete function, safe and stable, unique no water warning and automatic protection system, protect the
working life of the laser tube effectively. The power control system has unique automatic protection equipment to
ensure the stability and safety of the machine to the greatest degree.
· It supports various file formats PLT, BMP (1bit), DXF, AI etc. And it can carve various graphs and words.
· There are 6 liner guide rail in the balance moving system, step motor with lower speed components, it keep the
machine work with high precision.
Applicable material:
Wood, paper, leather, cloth, Plexiglas, epoxy resin, density board, double-colored board, marble, plastic, rubber, ceramic tile, crystal, bamboo and other non-metal materials.
Sample:
