3.2m Textile Printer/Flag Printer
Facebook Twitter Delicious Google Email this page
Product Details:
Model:
Select Payment and Shipping Terms:
Min. Order Quantity:
1 Set/Sets
Place of Origin:
Min. Order:
120
FOB Price:
0.00-0.00 /
Shippment Port:
Payment Terms:
T/T,Western Union
Show Buyers your Ability to Supply:
Production Capacity:
0
Delivery Time:
Packaging:
Ms. Rao Helen



Send a Message to this Supplier

Product Details Company Profile

MT-Starjet Series Textile Printer have been used most field such as advertisement printing textile digital printing, carpet digital printing, windows curtain digital printing and interior decoration printing and flax printing widely.


LOW COST

It is simple and leaves out heat transfer process one person can operates with high efficiency and short time.

Low cost and no need of any kind of interval paper, bearing the highest cost performance.

Adopting the most advanced thermal energy technology, Low power consumption, saves electricity, and conserve energy cost.


HIGH PRODUCTIVITY

Brand-New Printing Concert, Unnecessarily handmade plate making, printing directly.

Rapid speed and various printer to choose


MORE BUSINESS OPPORTUNITIES

Suitable for small lot, Personality, Diversity Printing, Without Limit Of Quantity.

The printed image color is bright and vivid with nice color gamut.


FEATURES

·Far Infrared Blackbody Tube Radiation Electrothermal Heating
·Intelligent PID Temperature Control
·Digital Tension Control
·Feeding Speed and Taking up Speed are Controllable
·Vacuum Fan Delivery is Controllable
·Quick Tail Gas Treatment
·Convenient to Maintain
·Easy to Set Up and Operate


Item MT-Starjet 7702L
Print head Two Epson DX7 Micro-Piezo
Number of Nozzles 1440nozzles per head
Color 4 Color: Cyan, Magenta, Yellow, Black
Height of print head
2-5mm
Size of ink-droplet
1.5pl-21pl
Printing Width
3.2m
Speed 3pass 42.5sq.m per hour
4pass 34.0sq.m per hour
6pass 25.0sq.m per hour
8pass 18.0sq.m per hour
Media Width 3300mm
Media take up Yes
Media feeder yes
Media payload 200kgs
Heating System Print Heater and Post heater with PID temperature control temperature range: room temperature to 80 centi degree
Ink Sublimation Ink
Water-based Dye Ink
Reactive printing ink
Ink Cartridge 8*350ml continuous ink supply
Rip Software Iprint3.0
Control Software Print Console
Operation System MS Windows XP& Windows7
Interface USB2.0
Power Voltage AC220-240V 50-60HZ or AC110-120V 50-60HZ
Printing Environment Temperature: 20-25 centi degree, Humidity: 40-60%
Printer dimension W4300*D900 * H1250mm
Packing dimension W4350*D930 * H730mm
Net Weight 320kgs
Gross Weight 550kgs
