Fiber Laser Welder Metal Aluminum Steel
Facebook Twitter Delicious Google Email this page
Product Details:
Model:
Select Payment and Shipping Terms:
Min. Order Quantity:
1 Set/Sets
Place of Origin:
Min. Order:
120
FOB Price:
USD 40000.00-100000.00 /
Shippment Port:
shanghai or as customers' order
Payment Terms:
L/C ,T/T
Show Buyers your Ability to Supply:
Production Capacity:
6000 Set/Sets
Delivery Time:
Year
Packaging:
Wooden case
Miss. Li Kelly



Send a Message to this Supplier

Product Details Company Profile

If need laser machine’s price list,pictures,specifications,delivery time and more,Welcome to contact GoldenLaser by:

Contact:   Ms Kelly Li

E-mail:     lijiao@goldenlaser.org

Website:  http://www.golden-laser.com.cn

Laser machine vidoes: https://www.youtube.com/user/goldenlaservivian

**************************************************************************************

To help us understand your machine requirments well,please kindly let me know below,then we can send most suitable machine’s detail information to you.

1,Which materila you need to cut or engrave?

2,What is the material size or thickness?

3,Which country will the machine be shipped to?

4,Which country will the machine be used?

5,Mostly,What is your full name,email,company name and website ?

****************************************************************************************

Laser welding has the superiority of small welding spot diameter, narrow weld seam and excellent welding effect. After welding, there is no need further treatment or merely simple further treatment. Furthermore, laser welding is applicable to a large scale of materials and can weld various different materials. There advantages enable laser welding be widely used in varieties of precision welding processes.



Applicable materials: welding gold, silver, platinum, stainless steel, titanium,copper,aluminium,stannum,nickel,chrome,columbium,alloy and other metal materials etc.

Applicable industries: metal plate processing industry,aviation, spaceflight, warship, landification, household appliance, commodity, medical, instrument, electronic and automobile etc. industries.



Laser types

YAG lamp pump laser generator

Laser wave length

1.064μm

Maximum power

300W

Single pulse maximum output power

150J

Output stability

±5%

Laser transmission mode

Flexible fiber

Power supply

Triphase AC 380V

Maximum input power

8kW

Size

L750xW1620xH1340

Working table (optional)

Precision electrical slide working table; galvanometer working table; robot device

Positioning accuracy

0.01mm

Cooling system

Internal & external double circulation heat exchange

heat exchange power

12.5kW

Quantity of fiber transmission branches

1~4

Storable laser type

32 types

Video monitoring (optional)

High-definition camera + 14 inch monitor

Format supported

dwg

Weight

450kg



Main Advantages of Laser Welding Machine:

1.Laser welding can control the heat input to the least demand quantity. Its range of metallographic change in the heat-affected zone is small. The deformation caused by the heat conduction can be controlled to minimum.

2.Laser welding doesnt use electrodes, so there is no electrode contamination or electrode damage. Furthermore, because it is non-contact welding process, equipment wear and deformation can be reduced to minimum.

3.Laser beam is easy to focus and be aligned and is easy be guided by optical instruments, so laser welding machines can be placed at the appropriate distance from the workplace and laser beam can be guided around the machine or through the obstacles. Other welding methods are unable to take effect due to the above space limitations.

4.The workpiece can be placed in hermetic space (under the control of vacuum or internal gas environment.)

5.Laser beam can be focused in a small area, so laser welding can weld small metal parts with close welding gap.

6.Laser welding is applicable to a large scale of materials and can weld various different materials.

7.Laser welding is easy to do automatic high-speed welding and can process under digital or computer control.

8.While welding thin metal sheets or thin wires, users will not be disturbed by the phenomenon of melt back as arc welding.

9.Laser welding is not affected by the magnetic field (arc welding and electron beam welding is easily to be affected) and can be accurately focused on the welded workpiece.

10.Laser welding is applicable to metals of two different physical properties (such as different resistance)

11.Laser welding does not need vacuum environment or X-ray protection.

12.Laser welding can use switch devices and optical fiber to transmit the laser beam to different work points, meeting the need of synchronized multi-position welding and non-simultaneous multi-position welding.
