H&H Aluminum channel letter bending mahcine
Facebook Twitter Delicious Google Email this page
Product Details:
Model:
H&H Aluminum
Select Payment and Shipping Terms:
Min. Order Quantity:
1 Set/Sets
Place of Origin:
Min. Order:
120
FOB Price:
USD 0.00-1.00 /Set
Shippment Port:
Qingdao
Payment Terms:
L/C ,T/T
Show Buyers your Ability to Supply:
Production Capacity:
100 Set/Sets
Delivery Time:
Month
Packaging:
Fumigate wooden case
Ms. Wu Lorna



Send a Message to this Supplier

Product Details Company Profile

Technical data:

Operating  principle

Automatic feed , slot and bend

Available material

Flat,Channel Aluminum

Slot angle

45°-135°

Bending radius

≥12mm

Feeding width

20mm≤Width≤128mm

Feeding thickness

Flat Aluminum: 0.3mm-1.2mm

Channel Aluminum: 0.3mm-1.0mm

Machine watt

≤1500W

Machine size

1350mm*700mm*1300mm

Machine weight

350KG

Voltage

220V/110V

Working air pressure

0.6Mpa


Characteristics:

1. Automatic feed , automatic notch, automatic bend

2. No need to fit the trimcap separately, simplified the fabricate process

3. High speed, stepper motors controlling system, it only takes 48 seconds to finish a 30cm height letter like “s”

4. Available material width ranges from 20mm to 128mm

5. Energy saving and environmental protection. Total power 1500w, actual service power less than 1500w.

6. Can read muti-vector file, the formats like dxf ,ai ,matching with the engraving software perfectly.

7. Size :1350*700*1300mm

8. processing materials: flat aluminum and channel aluminum. Processing width: 20mm-128mm  aluminum :0.3mm -1.2mm(flat), 0.3mm-1.0mm(channel)

9. Special specification of this equipment is available.
