Infiniti/Challenger stable printer FY-3278N with Seiko 510/50pl printhead
1.Low ink sensor, auto or manual ink supply system.
2.Double four color printing, vivid color & high speed .
3.X, Y axis AC servo motor Electric drive pinch roller
4. Individual color cleaning minimizes the waste of the ink..
5. 3 way intelligent heater (pre/print/post) helps bring more vivid output.
6. The entire printing platform and the girder are made of the alloy-aluminum which is strong,flat and quiet.
High printing quality, high resolution
Equipped with 12 Pcs 510/50pl heads
High resolution, CMYK 4 color printing
Excellent Design
Can print both flex banner, vinyl sticker, one way vision
Environmental Protection
Using solvent ink, suitable for both indoor and outdoor printing,
Small odor good for enviroment.
Professional Service
One year warranty for all machine
24 hours on line tech support
Specification:
| Modelmo |
FY-32712Y |
| Print Head |
Drop on demand Piezo Head |
| Number of Printhead |
4*3,spt 510/50pl |
| Maximun Print Width |
3200mm(125.98") |
| Print Speed |
Standard |
200 m2/hr |
| Quality |
153 m2/hr |
| High Quality |
120m2/hr |
| Media |
Max.width |
3300mm(129.92") |
| Max. Weight |
80kg |
| Type |
Frontlit,Backlit,Vinyl,Polyester,Window Film, Leater… |
| Thickness |
4mm(Max) |
| Heating System |
3 way intelligent heater |
Auto Media Feeding
&Take-up System |
Equipped |
| Ink |
Type |
Solvent ink (C,M,Y,K) |
| Capacity |
1L or 5L per Color Main Tank |
| Auto Cleaning System |
Positive Pressure Cleaning,Anti-Clogging Flash
Function&Capping System |
| Print interface |
USB2.0 |
| Power Specification |
220V/230V 50Hz/60Hz Printer:660W Heater:1900W |
| Operational Environment |
Temperature:20°C-28°C Humidity:40%-60% |
| Compatible RIP Software |
Photoprint,UltraPrint,Topaz,Wasatch,Caldera,Maitop |
Dimension
&Weight |
Machine |
4850cm*1020cm*1350cm 610kg |
| Package |
L4980mm X W1140mm X H1640mm 893kg
|
Challenger INKJET RINTER Details
Printing Software
Printing Sample
what our machine can print ?
A:PVC Flex Banner,Poster Paper,Photo Paper,Backlit Film,One Way,Vision Vinyl,Reflective
Film,Ceiling Mantle,Wall Paper/Decal,Car StickerMesh/Canvas,Adhesive PP,Transparent Films,
etc
where are they applicated ?
A:Large format light boxes,Outdoor displays,Airport light boxes,Building murals,In-storedisplays,
Wall paper decoration,Backlit bus shelter,etc
Shipment Term
1. By Sea : EXW or FOB 15-35 working days
2. By Air :EXW or CIF 7-15 working days
Our Certificate
After-Sales Service
1) Warranty Time: 1 year, within this period we will send spare part free to you if there are any problems with them (except artificial damage).
2) Quality: Quality of products will be strictly checked and every machine will be test to ensure it can works well before packaging.
3) Technical services: We have professional engineers available to service machinery overseas, once we receive your inquiry about fault we will reply you within 24 hours, and offer you any technical service about machine.
4) Lifelong Services: We provide lifelong services for all the products we sold out, and supply the spare
parts with competitive price.
5) File Services: We can supply Manual Specification, Operating Video and other files you need.
6) Language: We have a professional sales team who are good at English to ensure zero communication barriers.
