1.8m Epson DX7 Print Head
Facebook Twitter Delicious Google Email this page
Product Details:
Model:
MT-Starjet7702/MT-Starjet7701
Select Payment and Shipping Terms:
Min. Order Quantity:
1 Set/Sets
Place of Origin:
Min. Order:
120
FOB Price:
0.00-0.00 /
Shippment Port:
Payment Terms:
Show Buyers your Ability to Supply:
Production Capacity:
0
Delivery Time:
Packaging:
Ms. Rao Helen



Send a Message to this Supplier

Product Details Company Profile

Features

1. Epson DX-7 Micro Piezo print Technology
Epson DX-7 print head with micro piezo print technology can show not only the excellent printing quality, but also the durability to the Eco-solvent inks. Epson DX-7 print head has a longer and more durable working life. The improvement of printing precision makes the ink droplets smaller, and the stability is better than that of Epson DX-5 print head.

2. Dual Print Head Design
The technology of two print heads is the mature technology that we bring out to the market in the early stage for years. Now the product with two DX-7 print heads will definitely replace the previous version of printers with DX-5 print heads.

3. Comprehensive Media Handling
The standard media handling includes the automatic feeding&take up system that can load up as heavy as 200kgs. The heating system and hot air drying system which can now easily print on flex banner and diversity media.

4. 1.8m Printer also Available
For the best product coverage, the 1.8m printers with one Epson DX-7 print head(MT-Starjet 7701) model, and two Epson DX-7 heads(MT-Starjet 7702) model are also available for your easy choice and best buy.


Item
MT-Starjet 7702
MT-Starjet7701
Print head
Two Epson DX7 Micro-Piezo
One Epson DX7 micro-Piezo
Number of Nozzles
1440nozzles per head
Color
4 Color: Cyan, Magenta, Yellow, Black
Height of print head
2-5mm
Size of ink-droplet
1.5pl-21pl
Printing Width
1.82m
Speed
3pass
36.5sq.m per hour
20.0sq.m per hour
4pass
28.5sq.m per hour
16.0sq.m per hour
6pass
22.0sq.m per hour
11.5sq.m per hour
8pass
15.5sq.m per hour
8.5sq.m per hour
Media Width
1900mm
Media take up
Yes
Media feeder
yes
Media payload
70kgs
Heating System
Print Heater and Post heater with PID temperature control temperature range: room temperature to 80 centi degree
Ink
Eco Solvent Ink
Water-based Dye Ink
Reactive printing ink
Ink Cartridge
8*350ml continuous ink supply
Rip Software
Iprint3.0
Control Software
Print Console
Operation System
MS Windows XP& Windows7
Interface
USB2.0 & RS 232
Power Voltage
AC220-240V 50-60HZ or AC110-120V 50-60HZ
Printing Environment
Temperature: 20-25 centi degree, Humidity: 40-60%
Printer dimension
W2840*D900 * H1250mm
Packing dimension
W2920*D930 * H730mm
Net Weight
220kgs
Gross Weight
300kgs
