Equipment Type
|
UV1206
|
|
Printing length
|
1.2m
|
|
Printing width
|
0.6m
|
|
Printing head type
|
Ricoh Gen5
|
|
Printing head pcs
|
2-4 pieces
|
|
Printing resolution
|
720*2880 DPI
|
|
Printing speed
|
12-40㎡/h
|
|
Color mode
|
4 colors - 8 colors
|
|
Rip software
|
Photoprint DX10.0 KINCOLOR VERSION
|
|
Platform model
|
Suction platform
|
|
Suction platform area
|
1 design
|
|
Material thickness
|
0mm-70mm
|
|
Color range
|
1680million
|
|
Media type
|
PE,PP,ABS,PMMA,PS,PETG,PU,PVC,PVB,Acrylic,Glass,Wood,Metal,Leather and Wallpaper,marble,etc.
|
|
Image format
|
TIFF/JEPG/BMP/PDF/AI/EPS/PSD
|
|
Printing technology
|
Drop-on-demand piezo Electric
|
|
Positioning mode
|
Ink drop search positioning system
|
|
UV curing system
|
Intergration technology / HOENLE UV curable system / independent developed UV lightcuring system
|
|
X axis printing
|
Bidirectional printing and unidirectional printing
|
|
Y axis printing
|
Unlimited printing and repeatedly, pixel precision positioning
|
|
Printing head maintenance
|
Automatically cleaning and ink washer
|
|
Ink supply system
|
World famous SMC negative pressure ink supply system/ Intelligent mute negative system
|
|
Output port
|
USB
|
|
Power supply
|
50/60HZ 220V(±10%)>15A
|
|
Operation environment
|
Optimum temperature: 16-20℃ relative humidity: 40%-70%
|
|
Packing dimension
|
2900mm x1900mm x1570mm
|
|
Gross weight
|
600 kgs
|
